3.5 Inch Lift Kit GMC Sierra 1500 2WD/4WD (2019-2024)

Add vehicle to check this part fits
Fitment Notes
STARTING PRICE
$599.95
STARTING PRICE
$599.95
Configure Your Kit:
Select options
Order now and this part ships in:
0h : 42m : 29s

STARTING PRICE
$599.95

Lowest Price Guarantee

Select Matching Wheels and Tires
Select Matching Wheels and Tires
FREE Mount, Balance, and Shipping!

Features

GMC’s fifth-generation Sierra 1500 features an impressive all-new design that’s built from the ground up, with aggressive angles and head-turning stylings. Put the finishing touch on your truck with Rough Country’s 3.5in Upper Control Arm Suspension Lift!

Rough Country's 3.5in lift features a set of forged aluminum upper control arms to provide the correct suspension geometry in our most durable control arm to date!

This perfect-height lift is a great choice for anyone who wants more than a simple level but doesn’t quite want the full height of a 6-inch option. This kit lifts and levels the front of the vehicle with the rear, offering enough increased ground clearance to run up to 295/55R20 tires with an improved, aggressive look.

This kit includes Rough Country's premium N3 shocks! These 10-stage variable valving, high-pressure Nitrogen charged shocks offer a fantastic blend of off-road action and smooth highway ride quality. With a durable 18mm spring-loaded piston rod and faster-cooling 54mm shock body, this shock offers up to 36kN Tensile Strength for a long lifespan of impressive vibration dampening. Features natural rubber bushings and an eye-catching metallic silver paint.

This kit also features upgraded ball joints that are easy to install and maintenance free. These POM ball joints offer a greater range of motion for more wheel articulation than standard or OE replacements and feature a Polyoxymethylene ball race with an extremely low coefficient of friction for longer life, and a larger ball diameter to improve range of motion with a maintenance free design. Includes a Lifetime Replacement Guarantee!

  • Lifts and levels front of vehicle with rear.
  • Front Lift: 3.5in.
  • Rear Lift: 2in.
  • Increased ground clearance.
  • Includes forged aluminum control arms.
  • Control arms include POM ball joints for greater range of motion and easier installation.
  • Ball joints are pre-installed to ease installation.
  • Optional Vertex Coilovers

  • 8-Stage Adjustable Damping
  • Monotube Design
  • Nitrogen-Charged
  • Massive 2.5in Piston
  • 3-Stage Seal System
  • Heat-Treated, Alloy Bearing
  • 3-year Manufacturer's Warranty
  • Optional V2 Monotube Shocks

  • Incredible ride quality & performance
  • Monotube design
  • Nitrogen-charged
  • 46mm high-flow piston
  • Mounts inverted
  • 36kN Tensile Strength
  • 3-year Manufacturer's Warranty
  • Optional N3 Shocks

  • 10-Stage Variable Valving
  • High Pressure Nitrogen Charged
  • 35mm Piston
  • Chromed Hardened 18mm Piston Rod
  • 36kN Tensile Strength
  • Spring Loaded Piston Rod Seal
  • 3-year Limited Warranty
Fitment Notes
  • Fits short bed models ONLY.
  • Does NOT fit 2019 "Classic" models (2018 body style)
  • Does NOT fit GMC AT4.
  • Does NOT fit models with Adaptive Ride Control.
  • Optional N3 struts/Vertex Coilovers do NOT fit 2.7L or 3.0L models.

Est. Install Time 5-6 hours

Customer Support Headshot
Need Help?
Talk to a Build Expert

Installation

Instruction Sheet - Kit Installation

Instruction Sheet - Optional Strut Installation

Instruction Sheet - Optional Front Vertex Installation

Instruction Sheet - Optional Rear Vertex Installation
Est. Install Time:
5-6 hours
Front:
  • Strut Spacers
  • Forged Aluminum Upper Control Arms
  • Upper POM Ball Joints
  • Hardware
Rear:
  • 2in Fabricated Lift Blocks
  • U-bolts
  • Hardware
Shocks:
  • (2) Rear Premium N3 Series

GET IT INSTALLED

Don’t want to install it yourself? Search for installers in your area.


FITMENT

Vehicles
year
make
model
drive
2022
GMC
Sierra 1500 Limited
4WD
2022
GMC
Sierra 1500 Limited
RWD
2019 - 2024
GMC
Sierra 1500
4WD
2019 - 2024
GMC
Sierra 1500
RWD

Always read all product page details for more important fitment information

Wheels & Tires
Filters:
size
wheel
Bolt Pattern
Wheel Offset
note
Stance
285/60R20
Factory 20
6x5.5
-
-
0
295/55R20
Factory 20
6x5.5
-
-
0
32x11.50R17
17x8.5
6x5.5
+30
-
0
285/70R17
17x9
6x5.5
-12
-
1
295/70R17
17x9
6x5.5
-12
-
1
33x12.50R17
17x9
6x5.5
-12
Minor Trimming
1
285/65R18
18x9
6x5.5
-12
-
1
305/60R18
18x9
6x5.5
-12
-
1
33x12.50R18
18x9
6x5.5
-12
-
1
285/55R20
20x10
6x5.5
-25
Minor Trimming
1
305/55R20
20x10
6x5.5
-25
Trimming Required
1
33x12.50R20
20x10
6x5.5
-25
Trimming Required
1
285/55R20
20x9
6x5.5
-12
-
1
295/60R20
20x9
6x5.5
-12
Trimming Required
1
305/55R20
20x9
6x5.5
-12
Minor Trimming
1
33x12.50R20
20x9
6x5.5
-12
Minor Trimming
1
305/45R22
22x10
6x5.5
-25
-
1
33x12.50R22
22x10
6x5.5
-25
Trimming Required
1

Due to differences in manufacturing, dimension and inflated measurements, tire & wheel combinations should be test fit prior to installation
